ICM-45605
The ICM-45605 is an ultra high‑performance 6‑axis MEMS motion sensor family with the world’s first BalancedGyro™ technology and lowest power consumption. The sensor combines a 3‑axis gyroscope and a 3‑axis accelerometer in a compact 2.5 × 3 × 0.81 mm package.
Available variants
Features
Pedometer, Tilt Detection, Single/Double Tap Detection, Raise – Wake, Wake on Motion, Free-Fall Detection, Significant Motion Detection, Low-G Detection, High-G Detection
Product Features and Benefits
- Balanced Gyroscope Architecture
- 6-axis current: 0.42 mA (Low Noise mode)
- 6-axis current: 0.22 mA (Low Power Mode)
- Gyroscope Noise: 3.8 mdps/rtHz
- Accelerometer Noise: 70 μg/rtHz
- Temperature Stability: Gyro ±0.01 º/s/ºC Accel: ±0.15 mg/ºC
- On-chip APEX Motion Functions: Pedometer, Tilt Detection, Single/Double Tap Detection, Raise to Wake, Wake on Motion, Free-Fall Detection, Significant Motion Detection, Low-G Detection, High-G Detection
- FIFO Data Rate (FDR) for system power savings
- Host interface (I3C℠, I²C SPI) and I²C master interface
Target market & applications
- Hearables (TWS) and Wearables
- Virtual Reality
- Augmented Reality Glasses
- High-Accuracy Robotics
- Gaming Controllers
- Drones, Flight Controllers
Key attribute
Ultra high‑performance 6‑axis MEMS motion sensor family with the world’s first BalancedGyro™ technology and lowest power consumption
