Development Kit for ICP-10125 SmartPressure™ Sensor
The DK-10125 is a comprehensive development platform for ICP-10125, a High Accuracy, Low Power, Waterproof Barometric Pressure and Temperature Sensor IC. The platform designed around Microchip G55 MCU can be used by developers for rapid evaluation and development of ICP-10125 based solutions.
The DK-10125 includes an on-board Embedded Debugger so external tools are not required to program or debug the G55 MCU.
The development kit comes with necessary software including InvenSense MotionLink, a GUI based development tool and embedded Motion Drivers for ICP-10125. Embedded Motion Drivers (eMD) consists of a set of APIs to configure various aspects of the platform including ICP-10125 sensor parameters such as Raw Data, and Calibrated Data (Temp in ºC, Pressure in Pa).
MotionLink is a GUI based development tool included with the platform. It can be used to capture and visualize the sensor data from the motion sensor.
|3.55 × 3.55 × 1.45||Yes, 10 atm||30 – 110||1.3||I²C||1.8V||1.8V||Production|
|SmartPressure™ Development Kit for ICP-10125 Pressure Sensor|
