DK-42653

Development Kit for IIM-42653

The DK‑42653 is a comprehensive development platform for ICM‑42653, a high performance 6‑axis motion sensor that combines a 3‑axis gyroscope, and a 3‑axis accelerometer.

The platform, designed around Microchip G55 MCU can be used by developers for rapid evaluation and development of ICM‑42653 based solutions. The DK‑42653 includes an on-board Embedded Debugger so external tools are not required to program or debug the G55 MCU.

The development kit comes with necessary software including InvenSense Motion Link, a GUI based development tool and embedded Motion Drivers for ICM‑42653.

Embedded Motion Drivers (eMD) consists of a set of APIs to configure various aspects of the platform including ICM‑42653 sensor parameters such as full-scale range (FSR), output data rate (ODR), low-power or low-noise mode, and sensor interface to host (I3C℠, I²C, SPI).

MotionLink is a GUI based development tool included with the platform. It can be used to capture and visualize the sensor data from the motion sensor.


Product Details

ProductTypePackage
Size

(mm)
Gyro
Sensing Range

(º/sec)
Accel
Sensing Range

(g)
InterfaceCommentsPurchase

IIM-42653
6-Axis IMU2.5 × 3 × 0.91
14-pin LGA
±4000±32I3C℠ / I²C / SPIHigh FSR ±4000dps, ±32g, Low power, Extended Temperature Range

DK-42653
The DK-42653 is a comprehensive evaluation platform for IIM-42653. It enables quick development and evaluation of the IIM-42653 with the eMD software package.


Documentation & Resources

App Notes & User GuidesVersionUpdatedDownload
AN-000300 – SmartMotion Platform User Guide1.22024-02-16User Guide
AN-000393 – PCB Design Guidelines1.42024-01-19App Note
Software
(Note: Account required to download)
VersionUploadedDownload
SmartMotion Installer w/ MotionLink4.2.152024-02-15Download Zip File
DK-42653 SmartIndustrial eMD1.2.02024-01-22Download Zip File
