DK-20680A is a comprehensive development platform for IAM-20680, a high performance 6-axis motion sensor that combines a 3-axis gyroscope, and a 3-axis accelerometer.

The platform designed around a Microchip G55 microcontroller unit (MCU) can be used by developers for rapid evaluation and development of IAM-20680-based solutions. The DK-20680A includes an on-board embedded debugger so that external tools are not required to program or debug the G55 MCU.

The development kit comes with all the necessary software including InvenSense MotionLink, a GUI based development tool and embedded Motion Drivers for IAM-20680.

Embedded Motion Drivers (eMD) consist of a set of application programming interfaces (APIs) to configure various aspects of the platform including IAM-20680 sensor parameters such as full-scale range (FSR), output data rate (ODR), low-power or low-noise mode, Accelerometer, Gyroscope Calibration, and sensor interface to host (I2C, SPI).

Motion Link is a graphic user interface (GUI) based development tool included with the platform. It can be used to capture and visualize the sensor data from the motion sensor.

Product Details

Part # Gyro Full Scale Range Gyro Sensitivity Gyro Rate Noise Accel Full Scale Range Accel Sensitivity Digital Output Logic Supply Voltage Operating Voltage Supply Package Size
UNITS: (°/sec) (LSB/°/sec) mdps/rtHz (g) LSB/g (V) (V) (mm)
IAM-20680
IAM-20680
±250
±500
±1000
±2000
131
65.5
32.8
16.4
0.008
0.008
0.008
0.008
±2, ±4, ±8, ±16 16384
8192
4096
2048
I²C or SPI VDD 1.71V – 3.6V 3 × 3 × 0.75

Documentation & Resources

Features

  • IAM-20680 6-axis automotive grade motion sensor
  • Microchip G55 MCU with 512KB flash
  • On-board embedded debugger for programming and debugging
  • USB connectors for host interface to support software debug and sensor data logging
  • Board power supply through USB
